This drive voltage is AC80V. Can be matched a four-wire, six-wire, eight-wire two-phase hybrid stepping motor with currents below 6.0A and an outer diameter of 57-110mm.

BLDS2205 brushless DC motor driver is the latest high-tech product of our company for medium-power brushless motor. This product uses a large-scale integrated circuit to replace the original hardware design, with higher anti-interference and fast response. This product is suitable for driving any three-phase brushless DC motor, Hall or no Hall sensor, with peak current below 5A and power supply voltage between AC85V~264V. This driver features low temperature operation at high currents. The products are used in a series of electrical automation control fields such as knitting equipment, medical equipment, food packaging machinery and electric power tools.

◆Diameter 90,105,120mm for all IEC -flange motor available,other diameters available on request

◆Space saving assembled between motor and machine or gear flange

◆ Flange thickness 7-12mm

◆HTL (10-24VDC) version,TTL(5VDC) optional

◆1~5120 pulses per rotation,channel A and B

◆No electrical components exposed,grade IP67

◆Aluminum /stainless steel flange

Simple and compact structure, low heating and low noise, convenient installation, wide adaptability,  high working frequency, sensitive action, reliable braking and fast speed.

• Product Structure: hollow shaft
• Outside diameter (mm): 30
• Aperture / ShaftDiameter(mm):3,4,5,6,8,10
• Resolution (CPR): 100,200,256,360,400,500,512,1000,1024
• Operating voltage: 5V
• Output circuit: voltage output, open collector, line driver
• Small size,TTLcompatible

This driver  is suitable for driving any three-phase brushless DC motor, Hall or no Hall sensor, with peak current below 5A and power supply voltage between DC10V~50V. This driver features low temperature operation at high current. The products are used in a series of electrical automation control fields such as knitting equipment, medical equipment, food packaging machine and electric power tools.

This driver  is suitable for driving any three-phase brushless DC motor, Hall or no Hall sensor, with peak current below 10A and power supply voltage between DC10V~50V. This driver features low temperature operation at high current. The products are used in a series of electrical automation control fields such as knitting equipment, medical equipment, food packaging machine and electric power tools.

This driver  is suitable for driving any three-phase brushless DC motor, Hall or no Hall sensor, with peak current below 15A and power supply voltage between DC10V~50V. This driver features low temperature operation at high current. The products are used in a series of electrical automation control fields such as knitting equipment, medical equipment, food packaging machine and electric power tools.
